The figure below shows a micrometer screw gauge used to measure the diameter of a metal rod. When the rod is removed and the jaws...



The figure below shows a micrometer screw gauge used to measure the diameter of a metal rod. When the rod is removed and the jaws of the gauge are closed the reading is 0.14 mm. Determine the diameter of the rod.



Answers


Kavungya
Reading = 6.45 min
Diameter = 6.45 - 0.14
= 6.31 mm
Kavungya answered the question on May 27, 2019 at 04:27
