In the figure below NR is a diameter of the circle centre O. Angle PNR = 7500 ∠ NRM = 500 and ∠RPQ = 350. MRS and PQS are straight lines.
Giving reasons for every statement you write, find the following angles
(a) ∠ PQR
(b) ∠QSR
(c) Reflex ∠POR
(d) ∠ MQR



Answers


Kavungya
Kavungya answered the question on June 19, 2019 at 13:08
