In the figure below OA = a and OB =b. M is the midpoint of OA and AN:NB2: 1 (a) Express in terms of a and...



In the figure below OA = a and OB =b. M is the midpoint of OA and AN:NB2: 1
(a) Express in terms of a and b
(i)BA
(iii) BN
Iii ON
(b) Given that BX=hBM and OX=KON determine the values of h and k



Answers


Kavungya
Kavungya answered the question on September 23, 2019 at 06:18
